ADA4961

Data Sheet

Rev. A | Page 6 of 24

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage, VCCx

5.5 V

PWUP, A4/CLK, A3/CS, A2/FA, A1, and A0

3.6 V

Input Voltage, VIN+ and VIN−

+3.6 V to −1.2 V

θJA, Exposed Pad Soldered Down

50.92°C/W

θJC at Exposed Pad

42.24°C/W

Maximum Junction Temperature

140°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

240°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 5. Thermal Resistance

Package Type

θJA

θJC

Unit

24-Lead LFCSP

50.92

42.24

°C/W

ESD CAUTION
