AD627

Data Sheet

Rev. E | Page 24 of 24

OUTLINE DIMENSIONS

COMPLIANT TO JEDEC STANDARDS MS-001

CONTROLLING DIMENSIONS ARE IN INCHES; MILLIMETER DIMENSIONS

(IN PARENTHESES) ARE ROUNDED-OFF INCH EQUIVALENTS FOR

REFERENCE ONLY AND ARE NOT APPROPRIATE FOR USE IN DESIGN.

CORNER LEADS MAY BE CONFIGURED AS WHOLE OR HALF LEADS.

0.022 (0.56)

0.018 (0.46)

0.014 (0.36)

SEATING

PLANE

0.015

(0.38)

MIN

0.210 (5.33)

MAX

0.150 (3.81)

0.130 (3.30)

0.115 (2.92)

0.070 (1.78)

0.060 (1.52)

0.045 (1.14)

0.280 (7.11)

0.250 (6.35)

0.240 (6.10)

0.100 (2.54)

BSC

0.400 (10.16)

0.365 (9.27)

0.355 (9.02)

0.060 (1.52)

MAX

0.430 (10.92)

MAX

0.014 (0.36)

0.010 (0.25)

0.008 (0.20)

0.325 (8.26)

0.310 (7.87)

0.300 (7.62)

0.195 (4.95)

0.130 (3.30)

0.115 (2.92)

0.015 (0.38)

GAUGE

PLANE

0.005 (0.13)

MIN

Figure 53. 8-Lead Plastic Dual In-Line Package [PDIP]

Narrow Body (N-8)

Dimensions shown in inches (and millimeters)

CONTROLLING DIMENSIONS ARE IN MILLIMETERS; INCH DIMENSIONS

(IN PARENTHESES) ARE ROUNDED-OFF MILLIMETER EQUIVALENTS FOR

REFERENCE ONLY AND ARE NOT APPROPRIATE FOR USE IN DESIGN.

COMPLIANT TO JEDEC STANDARDS MS-012-AA

0.25 (0.0098)

0.17 (0.0067)

1.27 (0.0500)

0.40 (0.0157)

0.50 (0.0196)

0.25 (0.0099)

45°

8°

0°

1.75 (0.0688)

1.35 (0.0532)

SEATING

PLANE

0.25 (0.0098)

0.10 (0.0040)

5.00 (0.1968)

4.80 (0.1890)

4.00 (0.1574)

3.80 (0.1497)

1.27 (0.0500)

BSC

6.20 (0.2441)

5.80 (0.2284)

0.51 (0.0201)

0.31 (0.0122)

COPLANARITY

0.10

Figure 54. 8-Lead Small Standard Outline Package [SOIC_N]

Narrow Body (R-8)

Dimensions shown in millimeters (and inches)

ORDERING GUIDE

Model1

Temperature Range

Package Description

Package Option

AD627ANZ

−40°C to +85°C

8-Lead Plastic Dual In-Line Package [PDIP]

N-8

AD627AR

−40°C to +85°C

8-Lead Small Standard Outline [SOIC_N]

R-8

AD627AR-REEL

−40°C to +85°C

8-Lead Small Standard Outline [SOIC_N]

R-8

AD627AR-REEL7

−40°C to +85°C

8-Lead Small Standard Outline [SOIC_N]

R-8

AD627ARZ

−40°C to +85°C

8-Lead Small Standard Outline [SOIC_N]

R-8

AD627ARZ-R7

−40°C to +85°C

8-Lead Small Standard Outline [SOIC_N]

R-8

AD627ARZ-RL

−40°C to +85°C

8-Lead Small Standard Outline [SOIC_N]

R-8

AD627BNZ

−40°C to +85°C

8-Lead Plastic Dual In-Line Package [PDIP]

N-8

AD627BR

−40°C to +85°C

8-Lead Small Standard Outline [SOIC_N]

R-8

AD627BR-REEL

−40°C to +85°C

8-Lead Small Standard Outline [SOIC_N]

R-8

AD627BR-REEL7

−40°C to +85°C

8-Lead Small Standard Outline [SOIC_N]

R-8

AD627BRZ

−40°C to +85°C

8-Lead Small Standard Outline [SOIC_N]

R-8

AD627BRZ-RL

−40°C to +85°C

8-Lead Small Standard Outline [SOIC_N]

R-8

AD627BRZ-R7

−40°C to +85°C

8-Lead Small Standard Outline [SOIC_N]

R-8

1 Z = RoHS Compliant part.

registered trademarks are the property of their respective owners.

D00782-0-12/13(E)
