AD8227
Rev. 0 | Page 18 of
24
340
330
320
310
300
290
0
2
4
6
8
1012
1416
18
SUPPLY VOLTAGE (±VS)
20mV/DIV
4µs/DIV
NO LOAD
CL = 47pF
CL = 100pF
CL = 147pF
Figure 55. Small-Signal Pulse Response with Various Capacitive Loads,
G = 5, RL = Infinity
Figure 57. Supply Current vs. Supply Voltage
35
30
25
20
15
10
5
0
2
4
6
8
10
12
14
16
18
20
STEP SIZE (V)
SETTLED TO 0.001%
SETTLED TO 0.01%
Figure 56. Settling Time vs. Step Size, VS = ±15 V, Dual Supply
