AD8476

Data Sheet

Rev. B | Page 14 of 24

–140

–130

–120

–110

–100

–90

–80

–70

–60

–50

–40

–30

–20

–10

100

10k

100k

FREQUENCY (Hz)

HD2 (SINGLE-ENDED INPUT)

HD3 (SINGLE-ENDED INPUT)

HD2 (DIFFERENTIAL INPUT)

HD3 (DIFFERENTIAL INPUT)

Figure 41. Harmonic Distortion vs. Input Drive

–80

–120

–115

–110

–105

–100

–95

–90

–85

100

10k

100k

FREQUENCY (Hz)

VOUT = 2V p-p

VOUT = 4V p-p

VOUT = 8V p-p

Figure 42. Total Harmonic Distortion + Noise vs. Frequency

1µs/DIV

1V/DIV

200µV/DIV

0.01%/DIV

Figure 43. Settling Time to 0.01% of 2 V Step

–40

–35

–30

–25

–20

–15

–10

–5

–1.0

–0.8

–0.6

–0.4

–0.2

0.2

0.4

0.6

0.8

1.0

OUTPUT VOLTAGE (V)

VS = ±5V

Figure 44. Gain Nonlinearity

–20

–30

–40

–50

–60

–70

–80

–90

–100

–110

–120

–130

–140

100

10k

100k

FREQUENCY (Hz)

VS = 5V, RL = 2kΩ

VS = 5V, RL = NO LOAD

Figure 45. Spurious-Free Dynamic Range vs. Frequency at Various Loads

2µs/DIV

1V/DIV

20µV/DIV

0.001%/DIV

Figure 46. Settling Time to 0.001% of 2 V Step
