ADA4084-1/ADA4084-2/ADA4084-4

Data Sheet

Rev. H | Page 34 of 35

COMPLIANT

TO JEDEC STANDARDS MO-220-WGGC.

0.65

BSC

BOTTOM VIEW

TOP VIEW

EXPOSED

PAD

PIN 1

INDICATOR

4.10

4.00 SQ

3.90

0.50

0.40

0.30

SEATING

PLANE

0.80

0.75

0.70

0.05 MAX

0.02 NOM

0.20 REF

COPLANARITY

0.08

PIN 1

INDICATOR

0.35

0.30

0.25

2.60

2.50 SQ

2.40

FOR PROPER CONNECTION OF

THE EXPOSED PAD, REFER TO

THE PIN CONFIGURATION AND

FUNCTION DESCRIPTIONS

SECTION OF THIS DATA SHEET.

Figure 116. 16-Lead Lead Frame Chip Scale Package [LFCSP_WQ]

4 mm × 4 mm Body, Very Very Thin Quad

(CP-16-26)

Dimensions shown in millimeters

COMPLIANT TO JEDEC STANDARDS MO-153-AB-1

8°

0°

4.50

4.40

4.30

6.40

BSC

PIN 1

5.10

5.00

4.90

0.65 BSC

0.15

0.05

0.30

0.19

1.20

MAX

1.05

1.00

0.80

0.20

0.09

0.75

0.60

0.45

COPLANARITY

0.10

SEATING

PLANE

Figure 117. 14-Lead Thin Shrink Small Outline Package [TSSOP]

(RU-14)

Dimensions shown in millimeters
