Data Sheet

AD8597/AD8599

Rev. E | Page 5 of 20

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage

±18 V

Input Voltage

Differential Input Voltage1

±1 V

Output Short-Circuit to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Lead Temperature Range (Soldering 60 sec)

300°C

Junction Temperature

150°C

1

If the differential input voltage exceeds 1 V, limit the current to 5 mA.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

its exposed paddle soldered to a pad (if applicable) on a 4-layer

JEDEC standard PCB with zero air flow.

Table 5.

Package Type

Unit

8-Lead LFCSP_VD (CP-8-2)

78

20

°C/W

8-Lead SOIC (R-8) (AD8597)

140

39

°C/W

8-Lead SOIC (R-8) (AD8599)

120

36

°C/W

POWER SEQUENCING

Apply the op amp supplies simultaneously. The op amp supplies

must be stable before any input signals are applied. In any case,

the input current must be limited to 5 mA.

ESD CAUTION
