AD8646/AD8647/AD8648

Data Sheet

Rev. F | Page 6 of 18

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

Differential Input Voltage

±6 V

Output Short Circuit to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Lead Temperature (Soldering 60 sec)

300°C

Junction Temperature

150°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

soldered in a circuit board for surface-mount packages.

Table 4. Thermal Resistance

Package Type

Unit

8-Lead SOIC_N

125

43

°C/W

8-Lead MSOP

210

45

°C/W

10-Lead MSOP

200

44

°C/W

14-Lead SOIC_N

120

36

°C/W

14-Lead TSSOP

180

35

°C/W

ESD CAUTION
