ADA4091-2/ADA4091-4

Data Sheet

Rev. H | Page 6 of 20

ABSOLUTE MAXIMUM RATINGS

Table 5.

Parameter

Rating

Supply Voltage

36 V

Input Voltage

Refer to the Input

Overvoltage Protection

section

Input Current

±5 mA

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

1

Input current must be limited to ±5 mA.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

standard PCB with zero airflow. The exposed pad is soldered to

the application board.

Table 6. Thermal Resistance

Package Type

Unit

8-Lead SOIC (R-8)

155

45

°C/W

14-Lead TSSOP (RU-14)

112

35

°C/W

8-Lead LFCSP (CP-8-21)

75

12

°C/W

16-Lead LFCSP (CP-16-17)

55

14

°C/W

ESD CAUTION
