P9235A-R Datasheet

May 17, 2016

Table 5. Device Characteristic (Continued)

VIN = 5 V, VDDIO = 3.3 V, EN

¯¯ = 0V, LP = 6.5 µH, CP = 400 nF TA = -40C to +85C. Typical values are at 25°C, unless otherwise noted.

Symbol

Description

Conditions/Notes

Min

Typical

Max

Units

Clock Oscillators

FLSOSC

Low speed clock

kHz

FCLOCK

OSC clock frequency

MHz

FCENTER2

PLL VCO frequency

120

MHz

General Purpose Inputs/Outputs (GPIO)

VIH

Input high voltage

0.7*VDDIO

VIL

Input low voltage

0.3*VDDIO

ILKG

Leakage Current

-1.0

1 .0

µA

VOH

Output logic high

I=8mA

2.4

VOL

Output logic low

I=8mA

0.5

SCL, SDA (I2C Interface)

fSCL_MSTR

Clock Frequency

As I2C master

400

kHz

fSCL_SLV

Clock Frequency

As I2C slave

400

kHz

Capacitive load

For each bus line

100

CBIN

SCL, SDA Input Capacitance

5.0

ILKG

Leakage Current

1.0

µA

NOTES:

1. Do not externally load. For internal biasing only.

2. Guaranteed by design and not subject to 100% production testing
