AD8233
Data Sheet
Rev. 0 | Page 14 of 29
RIGHT LEG DRIVE (RLD) AMPLIFIER PERFORMANCE CHARACTERISTICS
140
–40
0.1
1
10
100k
10k
1k
100
FREQUENCY (Hz)
–20
0
20
40
60
80
100
120
0
–180
–160
–140
–120
–100
–80
–60
–40
–20
GAIN
PHASE MARGIN
Figure 34. Open-Loop Gain and Phase Margin vs. Frequency
1.5
1.0
0.5
0
–0.5
–1.0
–1.5
100
1M
100k
10k
1k
LOAD (Ω)
–40°C
+25°C
+85°C
Figure 35. Output Voltage Swing vs. Load
10k
1k
100
10
0.1
1
10
100k
10k
1k
100
FREQUENCY (Hz)
Figure 36. Voltage Spectral Noise Density vs. Frequency
5µV/DIV
1s/DIV
Figure 37. 0.1 Hz to 10 Hz Noise
5µV/DIV
200ms/DIV
Figure 38. 0.5 Hz to 40 Hz Noise
12
0
–40
100
TEMPERATURE (°C)
–20
20
0
406080
2
4
6
8
10
+VS = 1.8V
+VS = 3V
+VS = 3.5V
AC/DC = LOW, RLD SDN = HIGH
Figure 39. RLD Supply Current vs. Temperature
