background image
ADP7182
Data Sheet
Rev. I | Page 20 of 31
CH1 100mA BW
CH2 50mV
B
W M10µs A CH1
–122mA
T 10.00%
1
2
T
VOUT
LOAD CURRENT
Figure 75. Load Transient Response, VOUT = −5 V, ILOAD = −1 mA to −200 mA,
Load Step = 1 A/µs
CH1 100mA BW
CH2 50mV
B
W M40µs A CH1
–122mA
T 10.00%
1
2
T
VOUT
LOAD CURRENT
Figure 76. Load Transient Response, VOUT = −15 V, ILOAD = −1 mA to −200 mA,
Load Step = 1 A/µs, Noise Reduction Network
