Directional Coupler,

698-2700 MHz, Low PIM

Pulse Part Number DASCOUPxxDBNF Series

Electrical Specifications

Frequency (MHz) 698-2700 MHz

Nominal Impedance Ω 50Ω

VSWR ≤1.20

Insert Loss at Band DASCOUP10DBNF

≤0.7dB @698-2700 MHz

Isolation at Band DASCOUP10DBNF

≥30dB @ 698-2700 MHz

Insert Loss at Band DASCOUP6DBNF

≤1.6dB @698-2700 MHz

Isolation at Band DASCOUP6DBNF

≥26dB @ 698-2700 MHz

Directivity ≥20 dB

PIM ≤ -155 dBc (@ 243*43dBm)

Average Power Max 200 Watts

Peak Power Max 1000 Watts

Coupling DASCOUP6DBNF

6 dB

Coupling DASCOUP10DBNF

10 dB

Coupling Tolerance ± 1.0 dB

Mechanical Specifications

Connecto

N Female

Color

Black

Inner Contact Plating

Silver

Outer Trimetal Plating

Trimetal

Environmental Specifications

Operating Temperature

-30+85 ° C

Relativy Humidity

Up to 100%
