OrderingInformation

ApplicableDocuments

MIL-R-83401—ResistorNetworks,Fixed,Film,GeneralSpecifications

MIL-STD-105—SamplingProceduresandTablesforInspectionbyAttributes

MIL-STD-202—TestMethodsforElectronicandElectricalComponentParts

L 08 5 S 331 / 471 F LF XX

Model Series

Number of Leads:

4 thru 14

Circuit Type:

3 = Isolated

1 = Bussed

5 = Dual Terminator

M1 or M2 = Tube **

(No code used for standard bulk packaging.)

LF: RoHS Compliant

Tolerance Code:

F = ±1%

J = ±5%

(No code used for 2% standard.)

R2 Resistance Code:

(Add for -5 circuit only)

Resistance Code:

First 2 digits are significant.

Last digit denotes number of trailing zeros.

For "F" tolerance first 3 digits are significant.

Fourth digit denotes number of trailing zeros.

* Refer to Packaging for Automation section (Page A-3) for Ammo Pack capacity and dimensions.

** Refer to Packaging for Automation section (Page A-4) for M1 and M2 tube capacity and dimensions.

3T=AmmoPack,3leadsonlyattachedtotape.*

SIL Resistor Network

L Series
