MOUNTING HARDWARE FOR AVT PRODUCTS - Dimensions in inches (millimeters)

91 = 100 Style Horizontal 1 High Bracket

92 = 200 Style Push-In Bracket

93 = 300 Style Thru-Bolt Bracket

AVT SLIDERS-DIMENSIONS in inches (millimeters)



(RoHS COMPLIANT)

GLOBAL

PART NUMBER

FOR EXTRA

SLIDERS

SLIDER

MODEL

TYPE

DIMENSIONS

WIDTH

HEIGHT

HOLE

DIAMETER

75008602E29

AVT010, AVT020

70

0.187 (4.75)

0.516 (13.11)

0.125 (3.18)

75008603E29

AVT025, AVT25B,

AVT050, AVT50A,

AVT075

71

0.250 (6.35)

0.719 (18.26)

0.141 (3.58)

75008604E29

AVT25A, AVT50B,

AVT75A, AVT100

72

0.250 (6.35)

0.844 (21.44)

0.141 (3.58)

75008605E29

AVT130, AVT160,

AVT200, AVT225

73

0.312 (7.92)

0.797 (20.24)

0.170 (4.32)

Height

Hole

dia.

Width

BRACKET



TYPE

XY

Z

H

MOUNTING

SLOT

CB

101

1.063

(26.99)

0.500

(12.70)

0.950

(24.13)

1.000

(25.40)

0.219 x 0.438

(5.56 x 11.11)

0.750

(19.05)

1.375

(34.93)

102

1.063

(26.99)

0.750

(19.05)

0.859

(21.83)

1.250

(31.75)

0.219 x 0.438

(5.56 x 11.11)

0.750

(19.05)

1.750

(44.75)

103

1.063

(26.99)

1.250

(31.75)

1.000

(25.40)

1.500

(38.10)

0.281 x 0.563

(7.14 x 14.29)

0.927

(23.55)

2.125

(53.98)

BRACKET



TYPE

XHY

Z

HOLE

(DIA.)

202

0.478

(12.14)

0.250

(6.35)

0.125

(3.175)

0.375

(9.53)

0.170

(4.32)

203

0.583

(14.80)

0.580

(14.73)

0.188

(4.78)

0.460

(11.68)

0.115

(2.92)

204

0.700

(17.78)

0.578

(14.68)

0.250

(6.35)

0.500

(12.70)

0.156

(3.96)

205

0.846

(21.49)

0.800

(20.32)

0.375

(9.53)

0.600

(15.24)

0.343 x 0.213

(8.71 x 5.46)

206

0.846

(21.49)

0.800

(20.62)

0.375

(9.53)

0.600

(15.24)

0.343 x 0.213

(8.71 x 5.46)

207

0.700

(17.78)

1.125

(28.58)

0.500

(12.70)

0.687

(17.45)

0.250 x 0.188

(6.35 x 4.78)

0.046 (1.17)

C

Core length plus “X”

H

B

Z

H

Y

Core length

plus “X”

BRACKET



TYPE

X

(APPROXIMATE)

THREAD

301

0.373 (9.47)

8 to 32

302

0.271 (6.88)

8 to 32

303

0.463 (11.76)

1/4 to 20

MOUNTING HARDWARE

GLOBAL



MODEL

AVAILABLE BRACKET TYPES BY MODEL

91 = 100

STYLE

HORIZONTAL

1 HIGH

BRACKET

92 = 200

STYLE

PUSH-IN

BRACKET

93 = 300

STYLE

THRU-BOLT

BRACKET

AVT010

101

202

301

AVT020

101

203

301

AVT20A

101

203

301

AVT025

102

204

301

AVT25A

102

206

302

AVT25B

102

205

301

AVT050

102

204

302

AVT50A

102

206

302

AVT50B

102

208

302

AVT075

102

204

301

AVT75A

102

206

302

AVT100

102

206

302

AVT130

103

207

302

AVT175

103

207

303

AVT200

103

207

303

AVT225

103

207

303
