PRODUCT DATASHEET

1000BASE-T Copper SFP Transceiver

PART NUMBER

DFTO

DATE

REVISION

SHEET NO

SFPT-RJK-01

VICTOR

11/7/2014

0

6

OF

7

http://www.pulseelectronics.com/

V.

General Specifications

Notes:

1. Clock tolerance is +/- 50 ppm.

2. By default, it is a full duplex device in preferred master mode.

3. Automatic crossover detection is enabled.

External crossover cable is not required.

4. Does not support SGMII. With a SERDES the module will operate at 1000BASE-T only.

VI.

Environmental Specifications

VII.

Serial Communication Protocol

Support the 2-wire serial communication protocol outlined in the SFP MSA. It uses use an Atmel

AT24C02B 256 byte EEPROM with an address of A0h.

General

Parameter

Symbol

Min

Typ

Max

unit

Notes/Conditions

Data Rate

BR

10

1000

Mb/sec

IEEE 802.3 compatible.

See Notes 2 through 4 below

Cable Length

L

100

m

Category 5 UTP.

BER

Environmental Specifications

Parameter

Symbol

Min

Typ

Max

unit

Notes/Conditions

Case Operating

Temperature

Tcase

0

70

°C

Storage Temperature

Tsto

-40

85

°C

Ambient temperature
