FT51A Advanced MCU with 8051 Compatible Core IC Datasheet

Version 1.5

Doc ument N o.: FT _000877

C learance N o.: FT DI#420

7 Package Parameters

The FT51A is available in 4 package types. The package is lead (Pb) free, RoHS compliant, and uses a

‘green’ compound. The package is fully compliant with European Union directive 2002/95/EC.

7.1 48-Pin WQFN Package Outline

Figure 7-1 48 pin WQFN Package Marking

Figure 7-2 48 pin WQFN Package Dimensions

Note: The centre pad on the base of the FT51A is internally connected to ground. Dimensions are in mm.

FTDI

XXXXXXXXXX

FT51AQ

Line 1 – FTDI Logo

Line 4 – Date Code, Revision

Line 2 – Wafer Lot Number

Line 3 – FTDI Part Number

YYWW-C
