PSA10F Characteristics

WWW.PHIHONG.COM

INPUT:

AC Input Voltage Range

90 to 264VAC

AC Input Voltage Rating

100 to 240VAC

AC Input Frequency

47 to 63Hz

AC Input Current

0.3A RMS maximum at 120VAC

0.15A RMS maximum at 240VAC

Leakage Current

100uA maximum at 240VAC

Inrush Current

60A at 240VAC

OUTPUT:

Output Power

10W Continuous

Efficiency

DOE Level VI

EU CoC Ver5 Tier2

Standby Power

<100mW at 230VAC

Ripple and Noise

100mVp-p at 0A-1A load

200mVp-p at 1A-2A load

Current Limit

2.5A when less than 3V (auto-restart)

ENVIRONMENTAL:

Temperature

Operating

0 to 40C

Non-operating

-40 to +85C

Humidity

10 to 90%

EMI

FCC Class B, EN55022 Class B

Immunity

ESD:

EN61000-4-2

Level 3

Radiated:

EN61000-4-3

Level 2

EFT:

EN61000-4-4

Level 2

Surge:

EN61000-4-5

Level 3

C/T:

EN61000-4-6

Level 2

PFMT:

EN61000-4-8

VDT:

EN61000-4-11

Harmonic:

EN61000-3-2

Class A

Flicker:

EN61000-3-3

Dielectric Withstand (HI-POT) Test

Primary to secondary: 3000VAC, 10mA, 60 seconds

Insulation Resistance

Primary to secondary: 500V >7M OHM

FEATURES:

Over Voltage Protection

Auto-restart 6.3V maximum

Short Circuit Protection

Must withstand continuous short circuit

Over Temperature Protection

Auto shutdown without fault

DC Output

PSA10F-050 Micro-B USB: D+/D- Shorted

PSA10F-050(P) Standard Barrel: Center Positive 5.5x2.1x10mm

AC Input

US Fixed Blade folding prong

Interchangeable AC Clips (fit over US prongs)

FPBAG (FPE, FPK, FPS)

FPB:

Brazil

FPI:

India

FPC:

China

FPK:

UK

FPE:

Europe

FPN:

Argentina

FPH:

Korea

FPS:

Australia

(Sold Separately)
