Bill of material
STEVAL385LED4CH
8/10
DocID024374 Rev 2
Figure 5. STEVAL385LED4CH - layout (top layer)
63
2
R64, R66
10 K
RESC-0805
64
1
R65
2.7 K
RESC-0805
65
2
R71, R74
100 K
RESC-0603
Not mounted
66
1
U1
STMLUX38
TSSOP38
67
2
U2, U3
PM8834
SOI8
68
5
U4, U5, U6, U7, U10
LMV321ILT
SOT23-5L
Not mounted
69
1
U8
ST1S14
SO8-EP-9
70
1
U9
LK112M33TR
SOT23-5L
71
1
X1
16 MHz - N.M.
X32-3_2x2_5-MEC
Not mounted
Table 2. STEVAL385LED4CH - bill of material (continued)
Item Qty.
Reference
Part value
Decal
Note
