AMS00x • Embedded Bluetooth Low Energy Solution
Packaging, Handling & Storage, RoHS, Section 8
ADS-MS00x-107R • Preliminary Data Sheet
Page | 21
©2014-2015 ACKme Networks. http://ack.me
September 14, 2015
Figure 8 - Reel Specifications
Symbol
A
B
C1
D
E
H
T
Specification (mm)
2.5 ± 0.2
11 ± 0.2
330 ± 1
99.5 ± 0.1
13.2 ± 0.2
32.8 + 0.3 / -0.2
2.25 ± 0.2
