background image
DocID027777 Rev 2
33/49
LED6000
Application notes - step-down conversion
49
R6
4.7 k
0603
1% tolerance
R7
1.5 k
0603
1% tolerance
R8
47 k
0603
1% tolerance
R9
33 k
0603
1% tolerance
R12
100 k
0603
1% tolerance
R13
0.24
1210
1%, 0.5 W
PANASONIC ERJ14BQFR24U
L1
47
H
10 x 10
2.2 A sat. / 128 m
COILCRAFT MSS1038-473
D1
STPS2L60
SMBflat
60 V - 2 A Schottky rectifier
STM STPS2L60UF
D2
N. M.
U1
LED6000
HTSSOP16
STM LED6000
Table 7. LED6000 demonstration board component list (continued)
Reference
Part
Package
Note
Manufacturer P/N
