10-bit A/D converter (ADC)

ST7DALIF2

116/171

18.6

Interrupts

None.

18.7

18.7.1

Control/status register (ADCCSR)

Read/Write (Except bit 7 read only)

Reset Value: 0000 0000 (00h)

Bit 7 = EOC End of Conversion

It is cleared by hardware when software reads the ADCDRH register or writes to any bit of

the ADCCSR register.

0: Conversion is not complete

1: Conversion complete

Bit 6 = SPEED ADC clock selection

This bit is set and cleared by software. It is used together with the SLOW bit to configure the

ADC clock speed. Refer to the table in the SLOW bit description.

Bit 5 = ADON A/D Converter on

This bit is set and cleared by software.

0: A/D converter and amplifier are switched off

1: A/D converter and amplifier are switched on

Bits 4:3 = Reserved. Must be kept cleared.

Bits 2:0 = CH[2:0] Channel Selection

These bits are set and cleared by software. They select the analog input to convert.

Table 50.

Effect of low power modes on ADC

Mode

Description

Wait

No effect on A/D Converter

Halt

A/D Converter disabled.

After wakeup from Halt mode, the A/D Converter requires a stabilization time

tSTAB (see Electrical Characteristics) before accurate conversions can be

performed.

EOC

SPEED

ADON

CH3

CH2

CH1

CH0

Table 51.

Channel selection bits

Channel pin(1)

CH2

CH1

CH0

AIN0

AIN1

AIN2
