ST7DALIF2 datasheet(145/171 Pages) STMICROELECTRONICS

145 / 171 page

ST7DALIF2

Electrical characteristics

145/171

Table 86.

Output driving current

Symbol

Parameter

Conditions(1)

Min

Max

Unit

VOL

(2)

Output low level voltage for a standard

I/O pin when 8 pins are sunk at same

time

(see Figure 75)

IIO=+5 mA TA≤85° C

TA≥85° C

1.0

1.2

IIO=+2 mA TA≤85° C

TA≥85° C

0.4

0.5

Output low level voltage for a high sink

I/O pin when 4 pins are sunk at same

time

(see Figure 77)

IIO=+20 mA,TA≤85° C

TA≥85° C

1.3

1.5

IIO=+8 mA TA≤85° C

TA≥85° C

0.75

0.85

VOH

(3)

Output high level voltage for an I/O pin

when 4 pins are sourced at same time

(see Figure 83)

IIO=-5 mA, TA≤85° C

TA≥85° C

VDD-1.5

VDD-1.6

IIO=-2 mA TA≤85° C

TA≥85° C

VDD-0.8

VDD-1.0

VOL

(2)(4)

Output low level voltage for a standard

I/O pin when 8 pins are sunk at same

time (see Figure 74)

IIO=+2 mA TA≤85° C

TA≥85° C

0.5

0.6

Output low level voltage for a high sink

I/O pin when 4 pins are sunk at same

time

IIO=+8 mA TA≤85° C

TA≥85° C

0.5

0.6

VOH

(3)(4)

Output high level voltage for an I/O pin

when 4 pins are sourced at same time

IIO=-2mA TA≤85°C

TA≥85°C

VDD-0.8

VDD-1.0

VOL

(2)(4)

Output low level voltage for a standard

I/O pin when 8 pins are sunk at same

time

(see Figure 73)

IIO=+2 mA TA≤85° C

TA≥85° C

0.6

0.7

Output low level voltage for a high sink

I/O pin when 4 pins are sunk at same

time

IIO=+8 mA TA≤85° C

TA≥85° C

0.6

0.7

VOH

(3)(4)

Output high level voltage for an I/O pin

when 4 pins are sourced at same time

(see Figure 80)

IIO=-2 mA TA≤85° C

TA≥85° C

VDD-0.9

VDD-1.0

Subject to general operating conditions for VDD, fCPU, and TA unless otherwise specified.

The IIO current sunk must always respect the absolute maximum rating specified in Section 20.2 and the sum of IIO (I/O

ports and control pins) must not exceed IVSS.

The IIO current sourced must always respect the absolute maximum rating specified in Section 20.2 and the sum of IIO (I/O

ports and control pins) must not exceed IVDD.

Not tested in production, based on characterization results.
