2-OUTPUT CK420BQ DERIVATIVE

9SQL4952 DATASHEET

Ordering Information

“G” suffix to the part number are the Pb-Free configuration and are RoHS compliant.

“B” is the device revision designator (will not correlate with the datasheet revision).

Revision History

Part / Order Number Shipping Packaging

Package

Temperature

9SQL4952BNLGI

Trays

24-pin VFQFPN

-40° to +85° C

9SQL4952BNLGI8

Tape and Reel

24-pin VFQFPN

-40° to +85° C

Rev.

Issue Date

Intiator Description

Page #

F

11/4/2016

RDW

1. Updated test loads diagrams

2. Added typical Tdrive_PD# value

3. Slight adjustments to max REF slew rates

4. Added default impedance settings to Byte 12 and 13

4, 6, 10,

14

G

12/8/2016

RDW

1. Corrected impedance of differential test load from 100ohms to

85ohms

4
