FEATURES

Fast access time : 55ns

Low power consumption:

Operating current : 20/18mA (TYP.)

Standby current : 2µA (TYP.)

Single 2.7V ~ 5.5V power supply

All inputs and outputs TTL compatible

Fully static operation

Tri-state output

Data byte control : LB# (DQ0 ~ DQ7)

UB# (DQ8 ~ DQ15)

Data retention voltage : 2.0V (MIN.)

Lead free and green package available

Package : 44-pin 400 mil TSOP-II

48-ball 6mm x 8mm TFBGA

GENERAL DESCRIPTION

The AS6C2016 is a 2,097,152-bit low power

CMOS static random access memory organized as

131,072 words by 16 bits. It is fabricated using very

high performance, high reliability CMOS technology.

Its standby current is stable within the range of

operating temperature.

The AS6C2016 is well designed for low power

application, and particularly well suited for battery

back-up nonvolatile memory application.

The AS6C2016 operates from a single power

supply of 2.7V ~ 5.5V and all inputs and outputs are

fully TTL compatible

PRODUCT FAMILY

Power Dissipation

Product

Family

Operating

Temperature

Vcc Range

Speed

Standby(ISB1,TYP.)

Operating(Icc,TYP.)

AS6C2016 (I)

-40 ~ 85℃

2.7 ~ 5.5V

55ns

2µA

20/18mA

512K X 8 BIT LOW POWER CMOS SRAM

January 2007

128K X 16 BIT LOW POWER CMOS SRAM

FEBRUARY 2008

AS6C2016

FEBRUARY/2008, V 1.c

Alliance Memory Inc.

Page 1 of 13
