Ordering information scheme
TPI
6/9
Figure 9.
Connections
3
Ordering information scheme
Figure 10.
Ordering information scheme
Tip
Tip
1
IN
OUT
IN
OUT
8
27
36
45
GND
GND
Ring
Ring
1.
Connect pins 2, 3, 6 and 7 to
ground in order to guarantee a
good surge current capability for
long duration disturbances.
2.
To take advantage of the
“4-point” structure of the
TPIxxxN, the Tip and Ring lines
have to cross the device. In this
case, the device will eliminate the
overvoltages generated by the
parasitic inductances of the
wiring (LdI/dt), especially for very
fast transients.
TPI 80 1 1 N RL
Bidirectional Tripolar Protection
Breakdown voltage
Version
Package
Revision
Packing mode
80 = 80 V
1 = SO-8
RL = Tape and reel
Blank = Tube
