4 / 10 page

4 05/12/12

DC93163

ELECTRICAL CHARACTERISTICS (TA = 0°C to 70°C unless otherwise specified)

Switching Characteristics (TA = 0°C to 70°C, IF = 16mA, VCC = 5V unless otherwise specified)

* Typical values at TA = 25°C

ICPL0452 / ICPL0453 / ICPL0500 / ICPL0501

ISOCOM

COMPONENTS

Parameter

Symbol

Test Condition

Min

Typ.*

Max

Unit

Propagation Delay

Time to Logic Low

TPHL

ICPL0500

RL = 4.1kΩ, TA = 25°C

RL = 4.1kΩ

1.5

2.0

μs

ICPL0452/ ICPL0453 / ICPL0501

RL = 1.9kΩ, TA = 25°C

RL = 1.9kΩ

0.8

1.0

Propagation Delay

Time to Logic High

TPLH

ICPL0500

RL = 4.1kΩ, TA = 25°C

RL = 4.1kΩ

1.5

2.0

μs

ICPL0452/ ICPL0453 / ICPL0501

RL = 1.9kΩ, TA = 25°C

RL = 1.9kΩ

0.8

1.0

Common Mode

Transient Immunity

at Logic High

CMH

ICPL0500

IF = 0mA, VCM = 10Vp-p,

RL = 4.1KΩ, TA = 25°C

1000

V/μs

ICPL0452/ ICPL0501

IF = 0mA, VCM = 10Vp-p,

RL = 1.9kΩ, TA = 25°C

1000

ICPL0453

IF = 0mA, VCM = 1500Vp-p,

RL = 1.9kΩ, TA = 25°C

15000

Common Mode

Transient Immunity

at Logic Low

ICPL0500

IF = 16mA, VCM = 10Vp-p,

RL = 4.1kΩ, TA = 25°C

1000

V/μs

ICPL0452/ ICPL0501

IF = 16mA, VCM = 10Vp-p,

RL = 1.9kΩ, TA = 25°C

1000

ICPL0453

IF = 16mA, VCM = 1500Vp-p,

RL = 1.9kΩ, TA = 25°C

15000

CML
