ICPL0501SMT-R 데이터시트(PDF) 3 Page - ISOCOM COMPONENTS

부품명 ICPL0501SMT-R
상세설명  devices each consist of an infrared emitting diode,
PDF  10 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  ISOCOM [ISOCOM COMPONENTS]
홈페이지  http://www.isocom.com
Logo ISOCOM - ISOCOM COMPONENTS

ICPL0501SMT-R 데이터시트(HTML) 3 Page - ISOCOM COMPONENTS

  ICPL0501SMT-R Datasheet HTML 1Page - ISOCOM COMPONENTS ICPL0501SMT-R Datasheet HTML 2Page - ISOCOM COMPONENTS ICPL0501SMT-R Datasheet HTML 3Page - ISOCOM COMPONENTS ICPL0501SMT-R Datasheet HTML 4Page - ISOCOM COMPONENTS ICPL0501SMT-R Datasheet HTML 5Page - ISOCOM COMPONENTS ICPL0501SMT-R Datasheet HTML 6Page - ISOCOM COMPONENTS ICPL0501SMT-R Datasheet HTML 7Page - ISOCOM COMPONENTS ICPL0501SMT-R Datasheet HTML 8Page - ISOCOM COMPONENTS ICPL0501SMT-R Datasheet HTML 9Page - ISOCOM COMPONENTS Next Button
Zoom Inzoom in Zoom Outzoom out
 3 / 10 page
background image
3 05/12/12
DC93163
ELECTRICAL CHARACTERISTICS (TA = 0°C to 70°C unless otherwise specified)
COUPLED
* Typical values at TA = 25°C
ICPL0452 / ICPL0453 / ICPL0500 / ICPL0501
ISOCOM
COMPONENTS
Parameter
Symbol
Test Condition
Min
Typ.*
Max
Unit
Current Transfer Ratio
CTR
ICPL0500
ICPL0452/ ICPL0453 / ICPL0501
IF = 16mA, VO = 0.4V
VCC = 4.5V, TA = 25°C
7
19
50
50
%
ICPL0500
ICPL0452/ ICPL0453 / ICPL0501
IF = 16mA, VO = 0.5V
VCC = 4.5V
5
15
Logic Low Output
Voltage
VOL
ICPL0500
IF = 16mA, IO = 1.1mA,
VCC = 4.5V, TA = 25°C
0.18
0.4
V
ICPL0452/ ICPL0453 / ICPL0501
IF = 16mA, IO = 3mA,
VCC = 4.5V, TA = 25°C
0.18
0.4
ICPL0500
IF = 16mA, IO = 0.8mA,
VCC = 4.5V
0.5
ICPL0452/ ICPL0453 / ICPL0501
IF = 16mA, IO = 2.4mA,
VCC = 4.5V
0.5
