background image
5 25/07/2016
ICPLW50L
ISOCOM
COMPONENTS
DC93196
ELECTRICAL CHARACTERISTICS ((V
CC = 2.7 to 24V, IF = 3mA and TA = -40°C to 105°C,
unless otherwise specified)
ISOLATION
Note :
1.
A 0.1uF bypass capacitor must be connected across pin 6 and pin 4.
2.
CMH, Common Mode Transient Immunity in High stage is the maximum tolerable positive dVCM/dt on the leading edge of the common
mode impulse signal, VCM, to assure that the output will remain high (VO > 2.0V).
3.
CML, Common Mode Transient Immunity in Low stage is the maximum tolerable negative dVCM/dt on the trailing edge of the common
mode impulse signal, VCM, to assure that the output will remain low (VO < 0.8V).
Parameter
Symbol
Test Condition
Min
Typ.
Max
Unit
Insulation Voltage
VISO
t = 1 min,
TA = 25°C, RH ≤ 50%,
5000
V
Input - Output
Resistance
RI-O
VI-O = 500VDC
1012
Ω
Input - Output Insulation
Leakage Current
II-O
VI-O = 3kVDC, t = 5s,
TA = 25°C, RH 45%,
1.0
μA
