KEMET Part Number: SS30V-R300071

(UAL30VR3000710)

Commercial Grade, SS30V, 7100 uH

Dimensions

L

31mm +/-1mm

T

22.5mm +/-1mm

H

33mm +/-1mm

S

11mm +/-0.5mm

S1

19.5mm +/-0.5mm

F

0.8mm NOM

Packaging Specifications

Weight: 34.6 g

General Information

Style: Through-Hole Choke

Series: SS30V

Description: Common Mode Filter (Class B)

RoHS: Yes

Miscellaneous: Inductance Measurement

Condition: 1kHz 1V KC530

Notes:

Replacement For SS35V Type

And SS28V Type. Replacement

For SS35V Type And SS28V

Type

Specifications

Inductance: 7100 uH

Rated Temperature: 120C

Current: 3 Amps

Voltage AC: 250 VAC

DC Resistance: 120 mOhms

Insulation Resistance: 100 MOhms
