KMY 24
Data Sheet
3
1999-04-01
Output Signal
The phase difference between
V
D2 and VD1 is positive, if the target is receding from the
detector.
The phase difference between
V
D2 and VD1 is negative, if the target is approaching the
detector.
ϕ
1
ϕ
2
–
() 0
≥
EHA07261
Receding
Ch1 10 mV
Ch2
10 mV
100
Mms
V
D2
D1
V
ϕ
1
ϕ
2
–
() 0
≥
EHA07262
Approaching
Ch1 10 mV
Ch2
10 mV
100
Mms
V
D2
D1
V
