Material Specifications

Description

Material

Plating

Contact

Brass

Gold

30 µin minimum

Insulation

PTFE

Body

Brass

Nickel

100 µin minimum

Coupling Nut

Brass

Nickel

100 µin minimum

.

Environmental Specifications

Temperature

Operating Range

-65 to +165 deg C

Plotted and Other Data

Notes:

BNC Male Right Angle Connector Clamp/Solder Attachment for RG58, RG55, RG141, RG142, RG223, RG400, RG303, PE-

C195, PE-P195, LMR-195 from Pasternack Enterprises has same day shipment for domestic and International orders. Our

RF, microwave and millimeter wave products maintain a 99% availability and are part of the broadest selection in the industry.

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: BNC Male Right Angle Connector Clamp/Solder Attachment for RG58, RG55, RG141, RG142,

RG223, RG400, RG303, PE-C195, PE-P195, LMR-195 PE4053

URL: https://www.pasternack.com/bnc-male-standard-rg55-rg58-rg141-rg142-rg223-rg400-connector-pe4053-p.aspx

PE4053 REV 1.1

RF Connectors Technical Data Sheet

PE4053

BNC Male Right Angle Connector Clamp/Solder

Attachment for RG58, RG55, RG141, RG142, RG223,

RG400, RG303, PE-C195, PE-P195, LMR-195
