R
JCS730C
版本：201607A
6/14
特征曲线 ELECTRICAL CHARACTERISTICS (curves)
-75
-50
-25
0
25
50
75
100
125
150
0.8
0.9
1.0
1.1
1.2
Notes：
1. V
GS=0V
2. I
D=250μA
T
j
[℃]
-7 5
-5 0
-2 5
0
25
50
75
100
125
150
0 . 0
0 . 5
1 . 0
1 . 5
2 . 0
2 . 5
3 . 0
N o tes
：
1 . V
GS=10 V
2 . I
D=2.75 A
T
j [
℃]
Breakdown Voltage Variation
vs. Temperature
On-Resistance Variation
vs. Temperature
Maximum Safe Operating Area
For JCS730F
Maximum Drain Current
vs. Case Temperature
Maximum Safe Operating Area
For JCS730V/R/S/B/C
