MechanicalModel 데이터시트(PDF) 3 Page - Ledil, Inc. |
|
|
|||||||||||||||||||||||||||||
MechanicalModel 데이터시트(HTML) 3 Page - Ledil, Inc. |
|
|
3 / 66 page  A H B G 3 2 4 1 SCALE 1:1 WEIGHT (g) SHEET 1/1 SIZE A3 DRAWING TITLE Datasheet_FLORENCE-Z PART NUMBER MechanicalModel Ledil Oy Salorankatu 10 FIN 24240 SALO Finland THIRD ANGLE PROJECTION: This drawing is the property of LEDiL Oy. It may not be reproduced, copied or communicated without a written agreement with LEDiL Oy." Tolerances if not otherwise shown According to DIN ISO 2768-1 Linear measures: Up to 30mm class M, otherwise class C. According to DIN ISO 2768-2 Form and position: class L 286 26 13 182 280.82 124.85 13.1 200.75 85.25 LED position Bottom view 2 pcs M4 screws 4.9mm A B B Front view Isometric view SCALE 1:2 1.3 6.3 Detail A Scale: 2:1 3.47 5 Section view B-B Scale: 1:1 |
|
