3

Connectors

Description

Connector 1

Connector 2

Type

N Male

TNC Female Bulkhead

Specification

MIL-STD-348

Impedance

50 Ohms

50 Ohms

Contact Material and Plating

Beryllium Copper, Gold

Beryllium Copper, Gold

Contact Plating Specification

ASTM-B488, 50µ Inch.

ASTM-B488, 50µ In. Minimum

Dielectric Type

PTFE

PEI

Outer Conductor Material and Plating

Passivated Stainless Steel

Passivated Stainless Steel

Outer Conductor Plating Specification

SAE-AMS-2700

SAE-AMS-2700

Coupling Nut Material and Plating

Passivated Stainless Steel

Coupling Nut Plating Specification

SAE-AMS-2700

Hex Size

3/4 Inch

Torque

14 in-lbs [1.58 Nm]

Body Material and Plating

Passivated Stainless Steel

Passivated Stainless Steel

Body Plating Specification

SAE-AMS-2700

.

Environmental Specifications

Temperature

Operating Range

-55 to +125 deg C

RoHS Compliant

Yes

REACH Compliant

12/17/2015

Plotted and Other Data

Notes:

• Values at 25°C, sea level.

PE3C2276-12 REV 1.0

Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,

inventory and certifications: N Male to TNC Female Bulkhead Low Loss Cable 12 Inch Length Using PE-P142LL Coax,

RoHS PE3C2276-12

RF Cable Assemblies Technical Data Sheet

N Male to TNC Female Bulkhead Low Loss Cable

12 Inch Length Using PE-P142LL Coax, RoHS

PE3C2276-12
