LXXLD50
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
10 of 11
www.unisonic.com.tw
QW-R502-474.D
TYPICAL CHARACTERISTICS
Temperature, ( C)
20 40 60 80 100 120
-40 -20 0
0.6
0.7
0.8
1.0
0.9
1.1
VCNTL Supply Current vs. Junction Temperature
140
Reference Voltage vs. Junction Temperature
Temperature, ( C)
20 40 60 80 100 120
-40 -20 0
0.79
140
0.793
0.796
0.799
0.805
0.802
POK Delay
Time (µs)
VOUT1
VIN = 1.5V,
VCNTL = 5V,VOUT = 1.2V
-COUT = 220µF/6.3V, CIN
= 100µF/6.3V, RL=1Ω
VOUT
VPOK
