background image
https://www.phoenixcontact.com/pi/products/2313423
08/14/2018   Page 5 / 7
Repeater - PSI-REP-DNET CAN - 2313423
Schematic diagram
PORTB
PORTA
Device connections
Dimensional drawing
121
35
PSI–REP–DNET CAN
Ord.–No. 23 13 423
VCC
NET B
NET A
ACT
PORT B
TERM.
ON
PORT A
TERM.
ON
PORT
A
Application drawing
R
Stubline
Max.63devices
=Switchonbusterminationresistor
Branch line
Application drawing
R
R
R
Starstructure
=Switchonbusterminationresistor
Star structure
Application drawing
R
R
R
R
R
R
R
R
R
Treestructure
=Switchonbusterminationresistor
Tree structure
Application drawing
R
R
R
=Switchonbusterminationresistor
Linearstructure
Max.62devices
Max.62devices
Line structure
