08/14/2018   Page 2 / 7

Repeater - PSI-REP-DNET CAN - 2313423

Technical data

Ambient conditions

Permissible humidity (operation)

30 % ... 95 % (non-condensing)

Altitude

5000 m (For restrictions see manufacturer's declaration)

Degree of protection

IP20

Noise immunity

EN 61000-6-2

Serial interface

Interface 1

CAN interface, in accordance with ISO/IS 11898 for DeviceNet, CAN,

CANopen

Operating mode

Semi-duplex

No. of ports

2 (CAN_High / CAN_Low)

Connection method

COMBICON plug-in screw terminal block

File format/coding

Bit stuffing, NRZ

Transmission medium

2-wire twisted pair, shielded

Transmission method

CSMA/CA

Transmission length

≤ 5000 m (Dependent on the data rate and the protocol used)

Number of bus devices

≤ 64 (per potential segment)

≤ 63 (DeviceNet™, can be addressed logically)

Termination resistor

124 Ω (Integrated and ready to be switched)

Conductor cross section solid min.

0.2 mm²

Conductor cross section solid max.

2.5 mm²

Conductor cross section flexible min.

0.2 mm²

Conductor cross section flexible max.

2.5 mm²

Conductor cross section AWG min.

24

Conductor cross section AWG max.

14

Interface 2

CAN interface, in accordance with ISO/IS 11898 for DeviceNet, CAN,

CANopen

Operating mode

Semi-duplex

No. of ports

2 (CAN_High / CAN_Low)

Connection method

COMBICON plug-in screw terminal block

File format/coding

Bit stuffing, NRZ

Transmission medium

2-wire twisted pair, shielded

Transmission method

CSMA/CA

Transmission length

≤ 5000 m (Dependent on the data rate and the protocol used)

Number of bus devices

≤ 64 (per potential segment)

≤ 63 (DeviceNet™, can be addressed logically)

Termination resistor

124 Ω (Integrated and ready to be switched)

Conductor cross section solid min.

0.2 mm²

Conductor cross section solid max.

2.5 mm²

Conductor cross section flexible min.

0.2 mm²
