14

Standard

(A)

(B)

(C)

21.3

15.1

3

7.05

11

（32.7）

21.3

（11.4）

GT5-1S-HU

GT5-1P/S-R

（1.35）

GT5E-1P-DS(71)

5.25

13.67

For fixing pin

Ø1.3

For center

terminal

Ø1.2

For outer

terminal

2×Ø1.2

Panel

3

7.05

11

21.3

φ2.5

（32.7）

21.3

（11.4）

GT5-1S-HU

GT5-1P/S-R

（1.35）

Note

GT5-1P-DS

（70）

5.45

Panel

3

For center

terminal

φ1.2

For outer

terminal

2-φ1.2

2-φ3.2

Board Mounting Type

11.8

11.8

12.8

11.8

12.8

BRecommended PCB  

 Mounting Pattern

BRecommended PCB

 Mounting Pattern

BMated condition

BMated condition

Part No.

HRS No.

Material

／Plating or Color

Color

Key polarizing

code

Corresponding F

Connector Housing Packaging RoHS

GT5-1P-DS(70)

755-0007-5 70

Housing

：PBT／ー

Center terminal

：Brass／Tin plating

Insulator

：PBT／Dark Gray

Outer terminal

：Phosphor bronze／Tin plating

Light Gray Standard GT5-1S-HU

1

YES

GT5-1P-DS(A)(70)

755-0041-3 70

Brown

(A)

GT5-1S-HU(A)

GT5-1P-DS(B)(70)

755-0042-6 70

Green

(B)

GT5-1S-HU(B)

GT5-1P-DS(C)(70)

755-0083-3 70

Blue

（C）

GT5-1S-HU(C)

Note 1 : Use JIS B 1115 and 1122 class 4, nominal diameter 3, length 6 screws (for a board thickness of 1.6 mm) for the mounting screws.

Note 2 : Please use a mating F connector housing of a matching key type.

Part No.

HRS No.

Material

／Plating or Color

Corresponding F

Connector Housing Packaging RoHS

GT5EC-1P-DS(71)

755-0125-1 71

Housing

：PA／Natural

Center terminal

：Brass／Tin plating

Insulator

：PA／Black

Outer terminal

：Phosphor bronze／Tin plating

Fixing pin

：Brass／Tin plating

GT5-1S-HU

GT5R-1S-HU

1

YES

11.8

12.8
