18

Board

13.3

0.3（distance between

PCB and panel opening）

Combinaton Type (2 Coaxials + 1 Power contact)

F Connectors

17.28

25

（26.35）

※

（GT5-2/1S-R）

Housing

Retainer (Only for GT5-2/1S-HU)

M Connectors

Board mounting type

For power

supply terminal

φ

1.4

For outside

terminal

4×φ1.2

For inner

terminal

2×φ1.2

Panel

3

5.45

2×Ø3.5

21.3

23.3

Part No.

HRS No.

Material

Color

Packaging

RoHS

GT5-2/1S-HU

755-0009-0

PBT

Light Gray

1

YES

Part No.

HRS No.

Material

Color

Packaging

RoHS

GT5-2/1S-R

755-0003-4

PBT

Dark Gray

1

YES

Part No.

HRS No.

Material

／Plating or Color

Packaging

RoHS

GT5-2/1P-DS(70)

755-0014-0 70

Housing

：PBT／Light Gray

Center terminal

：Brass／Tin plating

Insulator

：PBT／Dark Gray

Outer terminal

：Phosphor bronze／Tin

plating

For power supply terminal

：Brass／Tin plating

1YES

Note :

Use JIS B 1115 and 1122 class 4, nominal diameter 3, length 6 screws (for a board

thickness of 1.6 mm) for the mounting screws.

BShown with inserted retainer.

*Used with separate retainer (GT5-

1P/S-R), which is sold separately.

BRecommended Board Mounting Pattern

BRecommended Panel Cut-out
