Distortion Calculations:

The M-8888 is capable of producing precise tone

bursts with minimal error in frequency (see the Actual

Frequecies vs Standard Requirements on page 5).

The internal summing amplifier is followed by a first-

order low-pass switched capacitor filter to minimize

harmonic components and intermodulation products.

The total harmonic distortion for a single tone can be

calculated using Equation 1, (see Equations on page

7), which is the ratio of the total power of all the extra-

neous frequencies to the power of the fundamental fre-

quency expressed as a percentage. The Fourier

components of the tone output correspond to V2f... Vnf

as measured on the output waveform. The total har-

monic distortion for a

dual tone can be calculated

using Equation 2, (see Equations on page 7).

V

intermodulation components. The internal switched

capacitor filter following the D/A converter keeps dis-

tortion products down to a very low level.

DTMF Clock Circuit

The internal clock circuit is completed with the addition

of a standard 3.579545 MHz television color burst

crystal. A number of M-8888 devices can be connect-

ed as shown in the Common Crystal Connection on

page 7 using only one crystal.

Microprocessor Interface

The M-8888 uses a microprocessor interface that

allows precise control of transmitter and receiver func-

tions. Five internal registers are associated with the

microprocessor interface, which can be subdivided

into three categories: data transfer, transceiver control,

and transceiver status. Two registers are associated

with data transfer operations. The receive data regis-

ter, a read-only register, contains the output code of

the last valid DTMF tone pair to be decoded. The data

entered in the transmit data register determines which

tone pair is to be generated (see the Tone

Encoding/Decoding Table on page 3). Data can only

be written to the transmit data register. Transceiver

control is accomplished with two control registers (and

CRB) that occupy the same address space. A write

operation to CRB can be executed by setting the

appropriate bit in CRA. The following write operation to

the same address will then be directed to CRB, and

subsequent write cycles will then be redirected to

CRA. Internal reset circuitry clears the control registers

on powerup; however, as a precautionary measure,

the initialization software should include a routine to

clear the registers. Refer to the Actual Frequencies vs

Standard Requirements Table on page 5 and the

Control Register A Description below for details on the

control registers. The IRQ/CP pin can be programmed

to provide an interrupt request signal on validation of

DTMF signals, or when the transmitter is ready for

more data (burst mode only). The IRQ/CP pin is con-

figured as an open-drain output device and as such

requires a pullup resistor (see the Single-Ended Input

Configuration on page 2).

Control Register B Description

Bit

Name

Function

Description

b0

BURST

Burst mode

A logic 0 enables the burst mode. When this mode is selected, data corresponding to the desired DTMF

tone pair can be written to the transmit data register, resulting in a tone burst of a specific duration (see

the 12 AC Characteristics on page 9). Subsequently, a pause of the same duration is induced.

Immediately following the pause, the status register is updated indicating that the transmit data regis-

ter is ready for further instructions, and an interrupt will be generated if the interrupt mode has been

enabled. Additionally, if call progress (CP) mode has bee enabled, the burst and pause duration is

increased by a factor of two. When the burst mode is not selected (logic 1), tone bursts of any desired

duration may be generated.

b1

TEST

Test mode

By enabling the test mode (logic 1), the IRQ/CP pin will present the delayed steering (inverted) signal

from the DTMF receiver. Refer to the Timing Diagrams on page 11 (b3 waveform) for details concerning

the output waveform.DTMF mode must be selected (CRA b1=0) before test mode can be implemented.

b2

S/D

Single/dual tone

A logic 0 will allow DTMF signals to be produced. If single-tone generation is enabled generation

(logic 1), either now or column tones (low or high group) can be generated depending on the state of

b3 in control register B.

b3

C/R

Column/row tones When used in conjunction with b2 (above), the transmitter can be made to generate single-row or sin-

gle-column frequencies. A logic 0 will select row frequencies and a logic 1 will select column frequen-

cies.
