background image
SSM2529
Data Sheet
Rev. 0 | Page 42 of 52
EQ_CTRL1 REGISTER
Table 129. Address: 0x54, Reset: 0x00, Name: EQ_CTRL1
Bits
Bit Name
Settings
Description
Reset
Access
[7:4]
EQ_RESERVED
Reserved
0x0
RW
3
EQ_UPDING
EQ coefficient updating flag
0x0
R
0
None
1
EQ coefficients updating
2
EQ_UPD_CLR
EQ coefficient update clear
0x0
W
0
Normal operation
1
Interrupt coefficient update
1
EQ_FORMAT
EQ coefficient format selection
0x0
RW
0
Normal
1
Large gain
0
EQ_UPD
EQ coefficient registers update flag
0x0
R
1
Update
0
None
EQ_CTRL2 REGISTER
Table 130. Address: 0x55, Reset: 0x00, Name: EQ_CTRL2
Bits
Bit Name
Settings
Description
Reset
Access
7
EQEN
EQ enable
0x0
RW
0
EQ disable
1
EQ enable
6
EQBP7
EQ Band 7 bypass when EQ enabled
0x0
RW
0
No bypass
1
Bypass EQ Band 7
5
EQBP6
EQ Band 6 bypass when EQ enabled
0x0
RW
0
No bypass
1
Bypass EQ Band 6
4
EQBP5
EQ Band 5 bypass when EQ enabled
0x0
RW
0
No bypass
1
Bypass EQ Band 5
3
EQBP4
EQ Band 4 bypass when EQ enabled
0x0
RW
0
No bypass
1
Bypass EQ Band 4
2
EQBP3
EQ Band 3 bypass when EQ enabled
0x0
RW
0
No bypass
1
Bypass EQ Band 3
1
EQBP2
EQ Band 2 bypass when EQ enabled
0x0
RW
0
No bypass
1
Bypass EQ Band 2
0
EQBP1
EQ Band 1 bypass when EQ enabled
0x0
RW
0
No bypass
1
Bypass EQ Band 1
