PBYG10Y

ISO 9001: 2015 CERTIFIED

TYPICAL DEVICE CHARACTERISTICS

PARAMETER

SYMBOL

VALUE

UNITS

Operating Temperature

T

A

-55 to 150

°C

Storage Temperature

T

STG

-55 to 150

°C

Peak Forward Surge Current, 8.3ms single half-sine wave superimposed on rated load.

I

FSM

50

Amps

Typical Thermal Resistance - Lead

R

ΘJL

40

°C/W

Typical Thermal Resistance - Ambient

R

ΘJA

80

°C/W

PART

NUMBER

DEVICE

MARKING

REPETITIVE

PEAK

REVERSE

VOLTAGE

V

RRM

VOLTS

MINIMUM

RMS

VOLTAGE

V

RMS

VOLTS

MAXIMUM

DC

BLOCKING

VOLTAGE

V

DC

VOLTS

MAXIMUM

AVERAGE

FORWARD

RECTIFIED

CURRENT

I

F(AV)

AMPS

MAXIMUM

FORWARD

VOLTAGE

@1.5A

V

F

VOLTS

MAXIMUM

REVERSE

LEAKAGE

CURRENT

@ V

RRM

I

R

µA

PBYG10Y

BYG10Y

1600

1120

1600

1.5

1.15

1

FIGURE 1

FORWARD CURRENT DERATING CURVE

0

0.4

0.8

1.2

T

0

25

50

75

100

125

150

175

1.6

FIGURE 2

TYPICAL FORWARD CHARACTERISTICS

V

0

0.5

1.0

1.5

2.0

2.5

3.0

0.001

0.01

0.1

1.2

100

1
