12 / 20 page

Tel: +86-755-66839118

Fax:+86-755-66839300

E-mail:uvsales@refond.com

eb: www.refonduv.com

PAGE:12

REFOND:WI-E-045

A/3

REV:E/3

TG-201709070731NP

2.3 Cardboard Box

Fig.2-5 Cardboard Box

2.4 Reliability Test Items And Conditions

Table 2-3 Reliability Test Items And Conditions

Test Items

Ref.Standard

Test Condition

Time

Quantity

Ac/Re

Reflow

JESD22-B106

Temp:260℃max

T=10 sec

3times.

10Pcs.

0/1

Temperature Cycle

JESD22-A104

100℃ 30 min.

↑↓5 min

-40℃

30 min.

300 Cycles

10Pcs.

0/1

Thermal Shock

JESD22-A106

-40℃ 15min

↑↓10s

100℃ 15min

300 Cycles

10Pcs.

0/1

High Temperature Storage

JESD22-A103

Temp:100℃

1000Hrs.

10Pcs.

0/1

Low Temperature Storage

JESD22-A119

Temp:-40℃

1000Hrs.

10Pcs.

0/1

Life Test

JESD22-A108

Ta=25℃

IF=100mA

1000Hrs.

10Pcs.

0/1

深圳市瑞丰光电子股份有限公司

SHENZHEN REFOND OPTOELECTRONICS CO.LTO.
