nRF24AP2-USB Product Specification

8.3

Current consumption

The power nRF24AP2 consumes depends on the configuration of nRF24AP2.

Note: The nRF24AP2-USB is not intended for battery power application. Use the nRF24AP2-1CH

or nRF24AP2-8CH for ultra low power applications.

Table 22. shows peak- and base current consumption for typical applications.

Conditions: TA = +25ºC

Table 22. Peak- and base current consumption for nRF24AP2

Symbol

Parameter (condition)

Notes

Min.

Typ.

Max.

Units

IIdle

No active channels—no

communications

9.3

ISuspend

Suspend control activated

500

µA

IPeakRX

Peak RX Current

a. Time of Maximum Current consumption in RX is typical 500 µs and maximum 1 ms.

IPeakTX

Peak TX Current at 0 dBm

b. Time of maximum TX Only Current is typical 300 µs and maximum 350 µs.

IPeakTX-6

Peak TX Current at -6 dBm

IPeakTX-12

Peak TX Current at -12 dBm

IPeakTX-18

Peak TX Current at -18 dBm
