nRF24AP2-USB Product Specification

Introduction

The nRF24AP2 components belong to Nordic Semiconductor’s low-cost, high-performance family of 2.4

GHz ISM Connectivity-on-Chip devices with the ANT protocol stack embedded. nRF24AP2 offers the

market’s most efficient, single chip, transceiver solution for Ultra Low Power (ULP) networks, through the

integration of the extremely power efficient ANT protocol stack, the world leading Nordic Semiconductor

2.4 GHz RF technology as well as critical low-power oscillator and timing features.

This document covers the product nRF24AP2-USB, which is a single-chip implementation of an ANT USB

bridge.

1.1

Prerequisites

In order to fully understand the product specification, a good knowledge of electronics and software

engineering is necessary. Please also refer to the document ANT Message Protocol and Usage when

reading this product specification. You can download the document from Nordic’s web site

www.nordicsemi.com or from www.thisisant.com.

1.2

Writing conventions

This product specification follows a set of typographic rules to ensure that the document is consistent and

easy to read. The following writing conventions are used:

•

Commands, bit state conditions, and register names are written in Courier New.

•

Pin names and pin signal conditions are written in Courier New bold.

•

Cross references are underlined and highlighted in blue.
