background image
ADAR2004
Data Sheet
Rev. 0 | Page 36 of 37
Address Name
Bits Bit Name
Description
Reset Access
0x07F
MULT_EN_MODE_15
7
BPF_MD15
Multiplier Mode 15 BPF Select
0x0
R/W
6
LOAMP_EN_MD15
Multiplier Mode 15 LO Amplifier Enable
0x0
R/W
5
MULT_LOW_RDY_MD15
Multiplier Mode 15 Low Band Ready Enable
0x0
R/W
4
MULT_LOW_ACT_MD15
Multiplier Mode 15 Low Band Active Enable
0x0
R/W
3
MULT_MID_RDY_MD15
Multiplier Mode 15 Mid Band Ready Enable
0x0
R/W
2
MULT_MID_ACT_MD15
Multiplier Mode 15 Mid Band Active Enable
0x0
R/W
1
MULT_HIGH_RDY_MD15
Multiplier Mode 15 High Band Ready Enable
0x0
R/W
0
MULT_HIGH_ACT_MD15
Multiplier Mode 15 High Band Active Enable
0x0
R/W
0x100
SCAN_MODE_EN
[7:1] RESERVED
Reserved
0x0
R
0
SCAN_MODE_EN
Scan Mode Enable
0x0
R/W
