0603-2 Package
13 Package Dimension
Recommended Solder Pad Footprint
*Sizes in mm
Notes：
H
This solder pad layout is for reference purposes only.
Unit: Millimeters
Dimension
Min.
Typ.
Max.
L
1.45
1.60
1.75
W
0.70
0.83
0.95
P
0.20
0.35
0.50
H
0.26
0.36
0.46
PESD1663U005
Rev :
www.leiditech.com
01.06.2015
5/7
