background image
ADMV1012
Data Sheet
Rev. A | Page 18 of 19
BILL OF MATERIALS
Table 6.
Qty.
Component
Description
Manufacturer/Part No.
1
Evaluation board
PCB
Analog Devices, Supplied/042365
4
C5, C7, C12
100 pF, high temperature, multilayer
ceramic capacitors, NP0, 0402
TDK/C1005NP01H101J050BA
4
C8, C10, C11
0.01 µF ceramic capacitors, X7R, 0402
Murata Manufacturing/GRM155R71E103KA01D
4
C3, C9, C13
1 µF ceramic capacitors, X5R, 0603
Murata Manufacturing/GRM188R61E105KA12D
7
GND, VDLO, VDRF, VGRF
CONN-PCB test points, compact mini,
CNKEY5019
Keystone Electronics Corporation/5019.00
4
LO_INPUT, RF_INPUT, IF_OUTPUT_LSB,
IF_OUTPUT_USB
CONN-PCB, SMA K_SRI-NS,
CNSMAL460W295H156
SRI CONNECTOR GAGE/25-146-1000-92
2
R1, R4
0 Ω resistor chips, SMD, JMPR, 0402
Panasonic/ERJ-2GE0R00X
1
X1
XFMR, power splitter/combiner,
2500 MHz to 4500 MHz,
TSML126W63H42
Mini-Circuits/QCN-45+
1
Device under test (DUT)
17.5 GHz to 24 GHz, GaAs, MMIC, I/Q
downconverter
Analog Devices Supplied/ADMV1012AEZ
1
Heatsink
Heatsink
Analog Devices Supplied/104365
