R7ML SPECIFICATIONS

ES-7805 Rev.11 Page 10/40

■ TEMPERATURE DATA CONVERSION

Temperature data (thermocouple and RTD) are represented in engineering unit value, °C or K, multiplied by 10 and ex-

pressed in 16 bits. °F data is represented in engineering unit value, without multiplication.

•Input Type K Thermocouple

Input Value

Converted Data, Decimal

Converted Data, Hex

≤ -272°C

-2720

F560

-150°C

-1500

FA24

1370°C

13700

3584

≥ 1472°C

14720

3980

14720 (3980)

13700 (3584)

-272 -150

-1500 (FA24)

-2720 (F560)

1370

1472

(°C)

I/O DATA DESCRIPTIONS

0

15

Input 0 (Output 0)

Input 1 (Output 1)

Input 2 (Output 2)

8 points

Input 15 (Output 15)

Input 3 (Output 3)

:

:

16 points

Input 7 (Output 7)

Input 8 (Output 8)

:

:

0 : OFF

1 : ON

■ DISCRETE I/O

0

15

16-bit binary data

Negative values represented in 2

’s complements

■ ANALOG I/O
