ADRF5515A

OUTLINE DIMENSIONS

©2021 Analog Devices, Inc. All rights reserved. Trademarks and

registered trademarks are the property of their respective owners.

One Analog Way, Wilmington, MA 01887-2356, U.S.A.

Rev. 0 | 15 of 15

Figure 30. 40-Lead Lead Frame Chip Scale Package [LFCSP]

6 mm × 6 mm Body and 0.95 mm Package Height

(CP-40-15)

Dimensions shown in millimeters

Updated: April 09, 2021

ORDERING GUIDE

Model1

Temperature Range

Package Description

Packing Quantity

Package

Option

ADRF5515ABCPZN

−40°C to +105°C

40-Lead LFCSP (6mm × 6mm w/ EP)

Reel, 0

CP-40-15

ADRF5515ABCPZN-R7

−40°C to +105°C

40-Lead LFCSP (6mm × 6mm w/ EP)

Reel, 750

CP-40-15

ADRF5515ABCPZN-RL

−40°C to +105°C

40-Lead LFCSP (6mm × 6mm w/ EP)

Reel, 2500

CP-40-15

EVALUATION BOARDS

Model

Description

ADRF5515A-EVALZ

ADRF5515A Evaluation Board
